Message Bridging

Overview

Message bridging enables smart contracts on different chains to communicate and execute functions across chains. This allows for complex cross-chain applications where contracts can trigger actions on other chains.

Figure 1: Complete message bridging flow from L2 to L1

Key Concepts

Cross-Chain Execution

Message bridging enables:

• Contract-to-Contract Communication: Smart contracts can call functions on other chains
• Cross-Chain State Updates: Contracts can update state on destination chains
• Complex Workflows: Multi-chain applications with coordinated execution
• Trustless Communication: Cryptographic verification of all cross-chain messages

Message Structure

Cross-chain messages contain:

• Destination Contract: Address of the contract to execute on destination chain
• Function Data: Encoded function call data
• Value: ETH value to send with the message (if any)
• Gas Limit: Maximum gas for execution on destination chain
• Metadata: Additional data for the message

Bridge Message Function

The bridgeMessage function initiates message transfers between chains.

Function Signature

function bridgeMessage(
    uint32 destinationNetwork,
    address destinationAddress,
    uint256 gasLimit,
    bytes calldata data
) external payable

Parameters

• destinationNetwork: Network ID of the destination chain
• destinationAddress: Address of the contract to execute on destination chain
• gasLimit: Maximum gas for execution on destination chain
• data: Encoded function call data

Process Steps

1. Validation: Check destination network is not the source network
2. Value Handling: Handle ETH value if provided
3. Event Emission: Emit BridgeEvent with message details
4. Tree Update: Add message to Local Exit Tree as leaf node

Example Usage

// Bridge a message to call a function on destination chain
bridgeMessage(
    1, // destinationNetwork (L2)
    0x..., // destinationAddress (contract address)
    100000, // gasLimit
    abi.encodeWithSignature("updateValue(uint256)", 123) // data
);

Claim Message Function

The claimMessage function claims and executes bridged messages on the destination chain.

Function Signature

function claimMessage(
    bytes32[_DEPOSIT_CONTRACT_TREE_DEPTH] calldata smtProofLocalExitRoot,
    bytes32[_DEPOSIT_CONTRACT_TREE_DEPTH] calldata smtProofRollupExitRoot,
    uint256 globalIndex,
    bytes32 mainnetExitRoot,
    bytes32 rollupExitRoot,
    uint32 originNetwork,
    address originAddress,
    uint32 destinationNetwork,
    address destinationAddress,
    uint256 gasLimit,
    bytes calldata data
) external

Parameters

• smtProofLocalExitRoot: Merkle proof for Local Exit Root
• smtProofRollupExitRoot: Merkle proof for Rollup Exit Root
• globalIndex: Global index identifying the message
• mainnetExitRoot: Mainnet Exit Root at time of message
• rollupExitRoot: Rollup Exit Root at time of message
• originNetwork: Network ID of source chain
• originAddress: Address that sent the message
• destinationNetwork: Network ID of destination chain
• destinationAddress: Address of the contract to execute
• gasLimit: Maximum gas for execution
• data: Encoded function call data

Process Steps

1. Validation: Verify destination network matches current chain
2. Proof Verification: Verify Merkle proofs against Global Exit Root
3. Duplicate Check: Ensure message hasn't been claimed before
4. Message Execution: Execute the message on destination contract
5. Claim Record: Mark message as claimed

Message Execution

// Execute the message on destination contract
(bool success, bytes memory returnData) = destinationAddress.call{
    value: msg.value,
    gas: gasLimit
}(data);

require(success, "Message execution failed");

Important Notes:

• Messages can only be executed if the destinationAddress is a smart contract that implements the IBridgeMessageReceiver interface
• If the receiving address is an EOA, the call will result as a success, meaning that the amount of ether will be transferred correctly, but the message will not trigger any execution
• If the native gas token is ETH, then transfer ETH to the destinationAddress and execute the message
• If ETH is not the native gas token, then mint WETH to the destinationAddress and execute the message

IBridgeMessageReceiver Interface

For a contract to receive bridged messages, it must implement the IBridgeMessageReceiver interface:

interface IBridgeMessageReceiver {
    function onMessageReceived(
        address originAddress,
        uint32 originNetwork,
        bytes calldata data
    ) external payable;
}

Parameters:

• originAddress: Address that sent the message on the source chain
• originNetwork: Network ID of the source chain
• data: The message data/metadata sent from source chain

Bridging Flows

L1 to L2 Message Bridging

L2 to L1 Message Bridging

L2 to L2 Message Bridging
