CDKCdk erigon
cdk-erigon-sovereign
This section describes the core components and flow of the cdk-erigon configuration across its three main deployment modes: sovereign, validium, and zkRollup. These configurations vary primarily in data availability and prover setup, while sharing the same core Erigon-based client and bridge infrastructure.
cdk-erigon-sovereign
| Component | Description / Link |
|---|---|
| Execution + Consensus Layer | CDK-Erigon — Combined Ethereum client for execution and consensus |
| AggKit - Oracle | AggOracle — Updates global Ethereum Root (GER) |
| AggKit - Sender | Sends certificates to Agglayer |
| Bridge API | zkEVM Bridge Service — Enables messaging between chains |
| Ethereum Bridge Contracts | zkEVM Contracts — Settlement layer contracts on Ethereum |
| Agglayer Network | Agglayer — Aggregation layer for certificates and proofs |
| Agglayer Node — Participates in Agglayer | |
| Agglayer Prover — Generates validity proofs |
cdk-erigon-zkrollup
| Component | Description / Link |
|---|---|
| Execution + Consensus Layer | CDK-Erigon |
| Internal CDK Infrastructure | Sequence Sender and Aggregator |
| Bridge API | zkEVM Bridge Service |
| Ethereum Bridge Contracts | zkEVM Contracts |
| Data Availability Layer | On-chain data submitted directly to Ethereum (no off-chain DAC) |
| Agglayer Network | Agglayer, Agglayer Node |
| Prover Network | Hermez Prover — zk-SNARK based proof generator |
cdk-erigon-validium
💡 Note: This mode shares the same architecture as
zkrollup, but uses an alternative data availability (DA) layer.
| Component | Description / Link |
|---|---|
| Execution + Consensus Layer | CDK-Erigon |
| Internal CDK Infrastructure | Sequence Sender and Aggregator — build and send transaction batches |
| Bridge API | zkEVM Bridge Service |
| Ethereum Bridge Contracts | zkEVM Contracts |
| Data Availability Layer | Custom DAC — Off-chain data availability committee |
| Agglayer Network | Agglayer, Agglayer Node |
| Prover Network | Hermez Prover — zk-SNARK based proof generator |
User Data Flow
The following diagram sequentially depicts the user data flow for the CDK FEP config in validium mode using a mock prover and an Agglayer connection.
Sequential Interactions
- The user sends a transaction to the CDK Erigon RPC node.
- The CDK Erigon RPC node proxies the data to the CDK Erigon sequencer node and syncs the batch data between the sequencer and the RPC nodes.
- The sequencer sequences the transaction batches.
- The sequencer sender reads batches from the RPC node.
- In validium mode only, the sequencer sender persists transaction data into the DAC nodes.
- The sequencer sender sequences the batches into the L1 smart contracts.
- The aggregator reads batches from the sequencer data stream.
- The aggregator sends batches to the provers.
- The aggregator submits the final proof to the Agglayer.
- The Agglayer submits the final proof to the L1 smart contract domain.
Mermaid Sequence Diagram
